UUGreenPower Co., Ltd has launched a new generation of Efficient Residential ESS with EV Charging Solution in Beijing, Shanghai, South Korea, Germany recently. Base on the 4 needs of global residential which including PV power generation, energy storage, charging and discharging, UUGreenPower is the first company in industry to integrates DC Bidirectional charging applications for EV into household storage products. UUGreenPower create the exclusive technology: Six in One Residential PV ESS, with a new generation of PV storage charging to build a new era of household storage industry.

High Integration: Integration Six Functions

UUGreenPower Residential PV ESS integrates six functions including PV, PCS, Battery, V2G, EMS and V2H with household energy and EV. Supports PV, battery and grid interactive to maximize the use of clean electricity to supply power to the household.

The system can directly use solar energy to power the household load and charge EV. The battery can be used as the family backup power supply to seamlessly provide uninterruptible power supply(UPS); When the power grid cuts off, the power of EV battery can also reversely supply power to household loads. Also support the Grid-Connected and Off-Grid mode, users can directly feedback the surplus power to the grid, and households can participate in the TOU power price and peak shaving power strategy to get the power spread benefits.

High Safety：Independent Air Duct Cooling Design with IP65 Protection

The system adopts UUGreenPower's independent air duct cooling design. High frequency isolation, to ensure components are completely isolated from air. The protection level up to IP65. Ultra-wide operating temperature range can run at -40℃ ~ 70℃, derates from 55℃. No need maintenance, stable and reliable in high humidity, dust, salt-flog and other complex environment.

The module has noise control strategy, with silent mode the acoustic noise ≤45dB, lower than daily ambient sound,to ensure the daily life are not affected.

Regarding protection features, it has leakage current detection, surge protection, anti-islanding protection and high frequency isolation at EV side, ensure the safety throughout the house. The expect life span is more than 10 years, and we can provide more than 5 years of warranty, to ensure long-term reliable operation for the end user.

More Economical: Flexible Expansion and Efficient Configuration

The grid-connected power of the system is downward compatible, can be adjusted to 6kW/4.6kW/3.8kW, to meet different grid-connected specifications at different countries.

MPPT short-circuit current> 16A, compatible with the latest 210mm high power module; can realize battery stacking by built-in DC-DC, and the battery capacity can be flexibly expanded up to 60kWh.

The installation adopts the high integration modular design with "PV energy storage inverter + energy storage battery + charging pile" to avoids the compatibility problems of different equipment and brands, meanwhile reduces the space, saves the cost, easy for installation and debugging, creates a cost-effective energy system for the household.

More Intelligent： One-Touch Intelligent Management

The control system adopts the human-computer interaction interface, user can choose the charge/discharge mode through the touch screen. Also matched with energy management APP, can configure and monitor parameters with APP, know the system real-time status as well as the power generation income. With EMS can adjust the household load requirement real-time.

Supports multiple working mode selections, including general mode/economic mode/backup mode. Users can flexibly configure power usage in real time based on their household power demand. It also has OTA function to support remote software upgrade , further reducing user costs.

To sum up, the new generation of Residential PV ESS with EV Charging Solution can effectively promote the use of household electricity. UUGreenPower always adheres to technological innovation, is committed to providing core charger modules and solutions for global customers. Empowering partners with technological innovation, to build a new era of Residential storage energy industry.
